Getting Started with curveRcore

Source: vignettes/getting-started.Rmd
getting-started.Rmd

Ecosystem orientation

curveRcore is the shared foundation of the curveR suite. It defines the data contract, preprocessing pipeline, forward models, analytical inverses and gradients, the calibration_result S3 class, and the eligibility-gating logic used identically by every fitting engine.

The three packages in the suite are:

  • curveRcore (this package) — preprocessing, model functions, inverses, gradients, the calibration_result class, eligibility gating, detection limits, and tidy extractors.
  • curveRfreq — frequentist NLS calibration via fit_calibration_freq() and fit_calibration_freq_multiplate().
  • curveRbayes — Bayesian calibration via Stan.

Both fitting engines return the same calibration_result object, so all downstream code — plots, extractors, detection-limit functions — works identically regardless of which engine produced the result.

For a complete end-to-end frequentist workflow, including the NLS algorithm, multi-start fitting, and sample back-calculation, see vignette("frequentist-quickstart", package = "curveRfreq"). This vignette covers the curveRcore layer that both engines share.

Installation

# From GitHub:
# devtools::install_github("immunoplex/curveRcore")

library(curveRcore)

Example datasets

curveRcore ships two synthetic multi-plate datasets that mirror the structure expected by the fitting pipeline. Both are named lists with the same six elements:

Element Description
standards Standard curve wells, one row per well.
blanks Blank well measurements (4 per plate).
samples Patient samples with dilution and response columns.
curve_id_lookup Maps integer curve_id to antigen / plate metadata.
response_var Name of the response column ("mfi" or "od").
indep_var Name of the concentration column ("concentration").

bead_assay_example — Luminex / bead-based immunoassay

Spans two antigens (alpha and beta) × three replicate plates, giving six curve_id values (1–6). The alpha curves were simulated with a Gompertz model; the beta curves with a 5PL model.

data(bead_assay_example, package = "curveRcore")
str(bead_assay_example, max.level = 1)
#> List of 6
#>  $ standards      :'data.frame': 60 obs. of  8 variables:
#>  $ blanks         :'data.frame': 24 obs. of  7 variables:
#>  $ samples        :'data.frame': 120 obs. of  13 variables:
#>  $ curve_id_lookup:'data.frame': 6 obs. of  5 variables:
#>  $ response_var   : chr "mfi"
#>  $ indep_var      : chr "concentration"
head(bead_assay_example$standards)
#>   curve_id stype sampleid well    dilution     mfi assay_response_variable
#> 1        1     S   STD_01   A1 1000.000000   109.4                     mfi
#> 2        1     S   STD_02   B1  333.333333   316.9                     mfi
#> 3        1     S   STD_03   C1  100.000000  1133.0                     mfi
#> 4        1     S   STD_04   D1   33.333333  4156.1                     mfi
#> 5        1     S   STD_05   E1   10.000000 12458.1                     mfi
#> 6        1     S   STD_06   F1    3.333333 18933.4                     mfi
#>   assay_independent_variable
#> 1              concentration
#> 2              concentration
#> 3              concentration
#> 4              concentration
#> 5              concentration
#> 6              concentration

elisa_assay_example — ELISA / optical density

Spans one analyte across six plates. Plates 1–3 were simulated with a 5PL model; plates 4–6 with Gompertz, reflecting realistic between-plate shape variation. The response column is "od".

data(elisa_assay_example, package = "curveRcore")
str(elisa_assay_example, max.level = 1)
#> List of 6
#>  $ standards      :'data.frame': 60 obs. of  8 variables:
#>  $ blanks         :'data.frame': 24 obs. of  7 variables:
#>  $ samples        :'data.frame': 120 obs. of  12 variables:
#>  $ curve_id_lookup:'data.frame': 6 obs. of  5 variables:
#>  $ response_var   : chr "od"
#>  $ indep_var      : chr "concentration"

The five forward models

All five canonical model functions live in curveRcore. They share a consistent parameter naming convention across the entire suite:

Parameter Role
a Lower asymptote (baseline response); a < d
b Scale / steepness parameter; b > 0
c Inflection-point location on the x-axis
d Upper asymptote (saturation response); d > a
g Asymmetry parameter (5-parameter models only); g > 0
x Independent variable — typically log₁₀(concentration)

The x pre-transformation (e.g. log₁₀) is applied upstream by preprocess_standards(); the model functions themselves are scale-agnostic.

logistic4 — 4PL (symmetric sigmoid)

y=a+d−a1+exp⁡(−x−cb)y = a + \frac{d - a}{1 + \exp\!\left(-\frac{x - c}{b}\right)}

Symmetric about its inflection point at (c,(a+d)/2)(c,\,(a+d)/2).

x <- seq(-3, 3, length.out = 200)
y <- logistic4(x, a = 1, b = 0.5, c = 0, d = 4)
plot(x, y, type = "l", ylab = "Response", main = "logistic4")

logistic5 — 5PL (asymmetric sigmoid)

y=a+d−a(1+exp⁡(−x−cb))gy = a + \frac{d - a}{\bigl(1 + \exp\bigl(-\frac{x-c}{b}\bigr)\bigr)^g}

Reduces to logistic4 when g=1g = 1. Values g>1g > 1 skew toward the upper asymptote; 0<g<10 < g < 1 skew toward the lower asymptote.

gompertz4 — Gompertz (intrinsically asymmetric)

y=a+(d−a)exp⁡(−exp⁡(−b(x−c)))y = a + (d - a)\,\exp\!\bigl(-\exp(-b\,(x - c))\bigr)

Asymmetric without requiring a fifth parameter — skewed toward the upper asymptote. Often the best fit for Luminex data.

loglogistic4 and loglogistic5

Classical Hill-equation parameterisations requiring x>0x > 0 (i.e. concentration on the natural scale, not log₁₀-transformed). When is_log_independent = TRUE, loglogistic4 is algebraically equivalent to logistic4 and is silently dropped by the fitting engines to avoid redundancy.

# List all recognised model names
available_models()
#> [1] "logistic4"    "loglogistic4" "gompertz4"    "logistic5"    "loglogistic5"

Preprocessing with preprocess_standards()

Neither curveRfreq nor curveRbayes preprocess data. All transforms must be applied upstream via curveRcore::preprocess_standards(). This clean separation ensures both fitting engines receive data on an identical scale, making their results directly comparable.

preprocess_standards() applies four steps in order:

  1. compute_concentration() — converts the dilution column to absolute concentration using the undiluted standard concentration; optionally log₁₀-transforms the result.
  2. correct_prozone() — dampens the hook effect at high concentrations by compressing post-peak signal toward the peak.
  3. perform_blank_operation() — applies one of five blank strategies: "ignored" (default), "included" (append geometric mean as an extra point), "subtracted", "subtracted_3x", or "subtracted_10x".
  4. compute_log_response() — applies log10() to the response. Values ≤ 0 are floored to 1 % of the minimum positive value before transformation.

Key contract: After preprocess_standards(), the column named by independent_variable holds log₁₀ concentration and the response column holds log₁₀ response. These are the scales the fitting engines expect.

std_raw   <- bead_assay_example$standards
blank_raw <- bead_assay_example$blanks

# Preprocess one curve at a time, then stack
std_preprocessed <- do.call(rbind, lapply(
  split(std_raw, std_raw$curve_id),
  function(df) {
    cid              <- df$curve_id[1]
    blanks_for_curve <- blank_raw[blank_raw$curve_id == cid, ]
    result <- preprocess_standards(
      data                 = df,
      antigen_settings     = list(standard_curve_concentration = 30),
      response_variable    = "mfi",
      independent_variable = "concentration",
      is_log_response      = TRUE,
      blank_data           = blanks_for_curve,
      blank_option         = "subtracted",
      is_log_independent   = TRUE,
      apply_prozone        = TRUE
    )
    result$data
  }
))

# Both columns are now on the log10 scale
head(std_preprocessed[, c("curve_id", "concentration", "mfi")])
#>     curve_id concentration      mfi
#> 1.1        1   -1.52287875 1.964654
#> 1.2        1   -1.04575749 2.476663
#> 1.3        1   -0.52287875 3.047580
#> 1.4        1   -0.04575749 3.616883
#> 1.5        1    0.47712125 4.094851
#> 1.6        1    0.95424251 4.276834

Adaptive constraint profile

adaptive_constraint_profile() is called internally before fitting to classify the assay signal into one of three scale classes and derive appropriate parameter bounds for the NLS or prior specification:

Scale class Criterion (log₁₀ response) Typical assay
"high" max > 2.5 Luminex / bead-based
"medium" max > 0.5 Mid-range ELISA
"low" max ≤ 0.5 Absorbance / OD

The scale class drives bound widths for b (slope) and g (asymmetry), and how far beyond the data range the inflection point c is allowed to roam. Calling this function directly is not usually necessary, but it is exported for custom constraint workflows.

The calibration_result object

Every fitting function in the curveR suite returns a single S3 object of class calibration_result. The structure is defined here in curveRcore; the fitting engines populate it.

# After fitting (e.g. via curveRfreq):
print(cr)    # concise summary
summary(cr)  # model selection table + best-model parameters

The object is a named list with six top-level components:

cr
├── $meta
├── $ensemble
├── $selection
├── $grid
├── $samples
└── $detection_limits

$meta — Provenance and fit configuration

$meta is a named list that records everything needed to reproduce or audit the fit. It is populated at construction time and never modified afterwards.

Field Type Description
method character "frequentist" or "bayesian"
package character Fitting package that produced the result
version character Package version string
curve_id character Unique identifier for this plate/antigen combination
response_var character Column used as the assay response
independent_var character Column used as the independent variable
is_log_response logical Whether the response was log₁₀-transformed before fitting
is_log_independent logical Whether concentration was log₁₀-transformed before fitting
timestamp POSIXct When the object was created

Additional fields such as antigen, plate, n_standards, n_samples, and pcov_threshold may be present depending on the calling package.

cr$meta$method           # "frequentist"
cr$meta$curve_id         # e.g. "plate1_antigen_A"
cr$meta$is_log_response  # TRUE

$ensemble — All models that were attempted

$ensemble is a named list with one entry per model that was fitted, keyed by model name (e.g. "logistic4", "gompertz4"). Even models that failed to converge have an entry, which is important for diagnosing why a preferred model was not selected.

Each entry contains:

Field Type Description
model_name character One of the five canonical model names
converged logical Whether the optimizer reached a solution
parameters data frame Parameter estimates with uncertainty (see below)
fit_stats named list Goodness-of-fit statistics
eligibility named list Output of assess_model_eligibility() for this model
grid data frame Per-model precision profile (populated for every converged model)
raw_fit object The raw fit object from nlsLM() or Stan (optional)

The parameters data frame columns differ slightly by framework:

Framework Columns
Frequentist term, estimate, std_error, statistic, p.value
Bayesian term, mean, sd, q2.5, q50, q97.5

The fit_stats list contains aic, bic, rmse, r_squared, and n_obs for frequentist fits, and loo_elpd, loo_se, waic for Bayesian fits.

Design note: Precision grids are computed for every converged model, not just the selected one. This means ensemble[[model]]$grid is available for the runner-up and can be inspected directly (see Section 6 below). The top-level $grid is simply a pointer to the best-model’s grid — no recomputation occurs.

# Check convergence across all models
sapply(cr$ensemble, `[[`, "converged")

# Inspect a specific model
cr$ensemble[["logistic4"]]$converged
cr$ensemble[["logistic4"]]$parameters
cr$ensemble[["logistic4"]]$fit_stats

$selection — Best model choice and eligibility record

$selection records the outcome of the two-stage selection process: eligibility gating followed by information-criterion ranking. It provides full transparency about which models were considered and why the winner was chosen.

Field Type Description
best_model_name character Name of the selected model, or NA if none converged
criterion character Selection criterion used, e.g. "AIC+eligibility"
fallback logical TRUE if no model passed all eligibility gates
fallback_reason character Human-readable explanation of any gate failures
eligible_models character vector Names of all models that passed eligibility gating
assessments named list Full assess_model_eligibility() output for every model
weights data frame AIC (or LOO) comparison table across all models
aic_best character Model that would have won by AIC alone (ignoring gates)

When aic_best != best_model_name, the AIC winner was demoted by a gate failure — a useful diagnostic for problem plates.

cr$selection$best_model_name   # "gompertz4"
cr$selection$criterion         # "AIC+eligibility"
cr$selection$fallback          # FALSE
cr$selection$eligible_models   # c("gompertz4", "logistic4")
cr$selection$aic_best          # may differ from best_model_name

$grid — Precision profile of the best model

$grid is a data frame of evenly-spaced predictions from the selected best model across the full fitted concentration range (default 200 points, configurable via n_grid). It is the primary input for plotting the calibration curve and for computing quantification limits.

Column Description
log10_concentration Concentration on the log₁₀ scale (x-axis)
concentration Concentration on the natural scale
x_fit The value passed to the model (equals log10_concentration when is_log_independent = TRUE)
predicted_response Forward model prediction at each grid point (on the fitting scale)
ci_lower, ci_upper Delta-method 95 % CI on the response scale
predicted_concentration Back-calculated concentration from the predicted response
se_concentration Delta-method SD of back-calculated log₁₀ concentration (uncapped)
pcov Percent CV derived from se_concentration, capped at cv_x_max
pcov_rmse Relative RMSE (%) — includes bias of predicted_concentration vs x_fit
pcov_pass Logical; whether pcov is below the acceptance threshold
d2y_dx2 Second derivative of log₁₀ response w.r.t. log₁₀ concentration (curvature)

The relationship between se_concentration and pcov is:

pcov=se_concentration×ln⁡(10)×100\text{pcov} = \text{se\_concentration} \times \ln(10) \times 100

se_concentration is the uncapped, modelling-scale quantity and is what downstream variance/weighting models (e.g. curveRweights) should consume. pcov is censored at cv_x_max and is intended for human-readable QC only.

Use pcov_from_se() and se_from_pcov() — the single canonical implementation of this conversion — rather than reimplementing it:

# Convert a vector of se_concentration values to pcov
se_vals  <- c(0.05, 0.08, 0.15)
pcov_from_se(se_vals)    # → percent CV values
#> [1] 11.51293 18.42068 34.53878

# And back
se_from_pcov(pcov_from_se(se_vals))   # round-trips exactly
#> [1] 0.05 0.08 0.15
head(cr$grid)
tidy_grid(cr)   # same, with curve_id column attached

$samples — Back-calculated concentrations for test samples

$samples is NULL if no test samples were supplied to the fitting function. When samples are present it is a data frame with one row per sample replicate:

Column Description
sampleid Sample identifier (carried through from input)
curve_id Plate/antigen identifier
raw_assay_response Original response value before any transform
observed_response_fit Response on the fitting scale
predicted_log10_concentration Back-calculated concentration on the log₁₀ scale
predicted_concentration Same as above when is_log_independent = TRUE
final_concentration Pre-dilution concentration: 10^predicted_concentration × dilution
se_concentration Delta-method SD of predicted_log10_concentration
pcov Percent CV of the back-calculated concentration, capped at cv_x_max
pcov_pass Logical; whether precision meets the acceptance threshold

Any additional columns present in the original sample data (dilution, replicate number, patient ID, etc.) are carried through unchanged.

cr$samples[, c("sampleid", "final_concentration", "pcov", "pcov_pass")]
tidy_samples(cr)   # same, with curve_id column attached

$detection_limits — LODs, MDC, and RDL

$detection_limits is NULL by default and is populated by calling compute_detection_limits(), either automatically inside the fitting pipeline or post-hoc:

The list has two sub-lists.

$lods — derived from the confidence interval on the lower asymptote a and upper asymptote d:

Field Description
lower_lod_response Upper 97.5 % CI of a; response threshold defining the lower LOD
upper_lod_response Lower 2.5 % CI of d; response threshold defining the upper LOD
lower_lod_log10_conc Lower LOD mapped to log₁₀ concentration
upper_lod_log10_conc Upper LOD mapped to log₁₀ concentration
lower_lod_conc Lower LOD on the natural concentration scale
upper_lod_conc Upper LOD on the natural concentration scale

$mdc_rdl — minimum detectable concentration and reliable detection limit, derived by inverting CI-modified versions of the fitted curve:

Field Description
mdc_lower_log10 / mdc_lower_conc Lower MDC (log₁₀ and natural units)
mdc_upper_log10 / mdc_upper_conc Upper MDC
rdl_lower_log10 / rdl_lower_conc Lower RDL (conservative: compressed d)
rdl_upper_log10 / rdl_upper_conc Upper RDL (liberal: expanded d)
cr$detection_limits$lods$lower_lod_conc
cr$detection_limits$lods$upper_lod_conc
cr$detection_limits$mdc_rdl$rdl_lower_conc

For multiplate results, use the convenience wrapper:

Eligibility gating

Why gates come before AIC

AIC and LOO-CV measure forward-fit quality — how well the model predicts the response values in the training data. They are completely blind to whether the fitted model can back-calculate concentration reliably. A model whose asymptote estimate is sitting on a constraint boundary, or whose covariance matrix is nearly singular, can have a lower AIC than a well-identified competitor purely by overfitting.

The eligibility gates intercept such models before AIC ranking. Only models that pass all applicable gates enter the ranking.

The four gates

All gates are evaluated by assess_model_eligibility():

Gate 1 — at_bound (frequentist only)

Checks that no parameter estimate lies within bound_tol (default 1e-4) of its lower or upper constraint bound. A boundary solution means the optimiser could not find an interior minimum — AIC asymptotics do not hold at the boundary.

Gate 2 — vcov_condition (frequentist only)

Computes the condition number κ of vcov(fit). If κ ≥ 1×10⁸, the covariance matrix is near-singular, making standard error propagation unreliable.

Gate 3 — rel_se (both frameworks)

Checks that SE / |estimate| < max_rel_se (default 5.0) for every free parameter. A relative SE larger than the estimate itself indicates an unidentified parameter.

Gate 4 — dynamic_range (requires the precision grid)

Locates the LLOQ and ULOQ — where pcov crosses pcov_threshold (default 20 %) — and requires ULOQ − LLOQ ≥ min_dynamic_range_log10 (default 0.5 log₁₀ units, approximately 3-fold).

Selection logic

After assessment, select_best_eligible() implements the following decision tree:

eligible_models ← {models that passed all gates}

if length(eligible_models) > 0:
    best ← eligible_models ranked by AIC (lowest) or LOO elpd (highest)
    fallback ← FALSE

else:                                        # fallback path
    best ← model with widest dynamic_range_log10;
            ties broken by AIC / LOO
    fallback ← TRUE
    fallback_reason ← per-model gate failure summary

The fallback ensures a result is always returned. When fallback = TRUE the selection is a best-effort choice and should be treated with caution.

Reading the gate results

Each model’s eligibility report is stored in ensemble[[model]]$eligibility. The $gates data frame has columns gate, passed, and detail:

for (nm in names(cr$ensemble)) {
  elig <- cr$ensemble[[nm]]$eligibility
  cat(sprintf("\n── %s  (eligible = %s) ──\n", nm, elig$eligible))
  print(elig$gates)
  cat(sprintf(
    "   LLOQ = %.3f  ULOQ = %.3f  DR = %.3f log10\n",
    elig$lloq, elig$uloq, elig$dynamic_range_log10
  ))
}
── gompertz4  (eligible = TRUE) ──
        gate passed detail
1   at_bound   TRUE
2 vcov_condition TRUE
3     rel_se   TRUE
4 dynamic_range  TRUE  dynamic range = 2.87 log10
   LLOQ = -2.341  ULOQ = 0.531  DR = 2.872 log10

── logistic4  (eligible = FALSE) ──
        gate passed              detail
1   at_bound  FALSE  b at lower bound
2 vcov_condition  TRUE
3     rel_se   TRUE
4 dynamic_range  TRUE  dynamic range = 1.94 log10
   LLOQ = -1.982  ULOQ = -0.041  DR = 1.941 log10

Per-model precision grids and LOQs

The d2y_dx2 column and shape-LOQ

Every precision grid includes a d2y_dx2 column: the second derivative d2(log⁡10y)/d(log⁡10x)2d^2(\log_{10} y) / d(\log_{10} x)^2 computed from the grid points with zero additional model evaluations via enrich_grid_with_d2y().

For a monotone increasing sigmoid this derivative has a peak below the inflection point, a zero crossing at the inflection point, and a valley above it. The shape-LLOQ (peak) and shape-ULOQ (valley) bracket the quasi-linear region of maximum assay sensitivity.

Shape-LOQs are stored in ensemble[[model]]$eligibility as shape_lloq_log10 and shape_uloq_log10 (plus natural-scale and response-scale counterparts), computed by compute_shape_loq_from_grid().

Comparing shape-LOQ with pcov-LOQ

The two LOQ families complement each other:

  • The pcov-LOQ (elig$lloq, elig$uloq) is precision-based: it identifies the concentration range where back-calculation %CV stays below pcov_threshold. It incorporates parameter uncertainty and observation noise.
  • The shape-LOQ is purely geometric: it marks where the curve changes curvature most rapidly, independent of measurement uncertainty. It typically gives a tighter (narrower) range.
best_nm  <- cr$selection$best_model_name
elig     <- cr$ensemble[[best_nm]]$eligibility

data.frame(
  Metric     = c("Shape-LLOQ", "Shape-ULOQ", "pcov-LLOQ", "pcov-ULOQ"),
  log10_conc = c(elig$shape_lloq_log10, elig$shape_uloq_log10,
                 elig$lloq, elig$uloq),
  conc       = 10^c(elig$shape_lloq_log10, elig$shape_uloq_log10,
                    elig$lloq, elig$uloq)
)

Tidy extractors

The canonical way for downstream packages and user code to access predictions is through the tidy extractor functions. Do not reach into the object internals directly — the extractors dispatch automatically to both the single-plate and multiplate classes.

tidy_samples() — sample predictions

# Single plate
s <- tidy_samples(cr)

# Multiplate: row-binds all plates with curve_id attached
s_all <- tidy_samples(mp)
head(s_all[, c("curve_id", "sampleid", "final_concentration",
               "se_concentration", "pcov", "pcov_pass")])

tidy_grid() — precision profiles

# Best-model grid for a single plate
g <- tidy_grid(cr)

# Multiplate: all grids row-bound with curve_id
g_all <- tidy_grid(mp)

# Inspect a non-selected model's grid:
g_runner_up <- tidy_grid(cr, model = "logistic4")

Multi-plate objects

When multiple plates are fitted together the result is a calibration_result_multiplate object — a named list with $meta and $plates, where each element is a complete single-plate calibration_result.

mp$plates[["1"]]   # a full calibration_result for curve_id 1

# Global metadata
mp$meta$method
mp$meta$n_curves

# Tidy extractors work identically
tidy_samples(mp)
tidy_grid(mp)
compute_detection_limits_multiplate(mp)

Cross-method comparison

When the same data has been fitted by both curveRfreq and curveRbayes, three comparison utilities are available:

# Merge prediction grids (columns prefixed by method name)
compare_calibrations(cr_freq, cr_bayes)

# Side-by-side parameter table with relative differences
compare_parameters(cr_freq, cr_bayes)

# Paired sample predictions with agreement columns
comp <- compare_samples(cr_freq, cr_bayes)
head(comp[, c("sampleid",
              "frequentist_final_concentration",
              "bayesian_final_concentration",
              "conc_diff")])

# Agreement metrics (bias, MAE, RMSE, Pearson r, Lin's CCC)
agreement_metrics(
  cr_freq$samples$predicted_log10_concentration,
  cr_bayes$samples$predicted_log10_concentration
)

Summary

curveRcore provides six interconnected layers shared by all fitting engines:

  1. Datasets — bead_assay_example (Luminex) and elisa_assay_example (ELISA) for testing and documentation.

  2. Forward models — logistic4, logistic5, gompertz4, loglogistic4, loglogistic5; consistent a / b / c / d / g parameterisation throughout.

  3. Preprocessing — preprocess_standards() applies concentration computation, prozone correction, blank handling, and log₁₀ transforms in a fixed, reproducible order.

  4. Inverses and gradients — closed-form analytical inverses and delta-method gradients for all five models, used for back-calculation and uncertainty propagation.

  5. Eligibility gating — assess_model_eligibility() and select_best_eligible() intercept unidentified or boundary-constrained models before AIC / LOO ranking.

  6. Result class and extractors — calibration_result (single plate) and calibration_result_multiplate; tidy extractors tidy_samples() and tidy_grid(); pcov / SE conversion utilities; detection-limit functions; and cross-method comparison helpers.
